OEM Yellow Powder Coated Escalator Floor Plate Pitch 8.466 Aluminum Moving Walk Comb

Product Categories

Modern ElevatorTechnology Service（Guangdong）Co, Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: OEM Yellow Powder Coated Escalator Floor Plate Pitch 8466 Aluminum Moving Walk Comb
Brand: Chinese brand
Price: 1 USD

Brand Name : Chinese brand

Model Number : COMB-84101

Certification : CNAS Type Test Certificate

Place of Origin : China

MOQ : 1 set landing floor plate

Payment Terms : T/T

Delivery Time : 15 working days

Comb material : Aluminum

Comb teeth pitch : 8.466mm

Finish : Yellow Powder Coated

FastenHolesDistant : 101.7mm

Contact Now

Moving Walk Spare Part, Pitch 8.466 Comb, Aluminum With Yellow Powder Coated for Left Side Comb

Pitch P=8.466 Moving Walk Comb Specification

Item	Order Code	Description	W (mm)	Finish	D (mm)	Remarks	OEM #
1	COMB-84101-203RA	comb middle	203	Raw Alu	101.7		GAA453BV1
2	COMB-84101-203YPC	comb middle	203	Yellow Powder Coated	101.7		GAA453BV11
3	COMB-84101-206RA	comb side right	206	Raw Alu	101.7		GAA453BV5
4	COMB-84101-206YPC	comb side right	206	Yellow Powder Coated	101.7		GAA453BV15
5	COMB-84101-206RA-PI	comb side right	206	Raw Alu	101.7	For pallet with plastic insert	GAA453BV3
6	COMB-84101-206YPC-PI	comb side right	206	Yellow Powder Coated	101.7	For pallet with plastic insert	GAA453BV13
7	COMB-84101-199RA	comb side left	198	Raw Alu	101.7		GAA453BV6
8	COMB-84101-199YPC	comb side left	199	Yellow Powder Coated	101.7		GAA453BV16
9	COMB-84101-199RA-PI	comb side left	199	Raw Alu	101.7	For pallet with plastic insert	GAA453BV7
10	COMB-84101-199YPC-PI	comb side left	199	Yellow Powder Coated	101.7	For pallet with plastic insert	GAA453BV17

Comb DGW

OEM Yellow Powder Coated Escalator Floor Plate Pitch 8.466 Aluminum Moving Walk Comb
